Earthquaker Devices Sunn O))) HalfLife™ Octave Distortion + Booster Pedal

Description

Sunn O))) and EarthQuaker Devices are pleased to bring you the most compact, pedalboard-friendly version of the Life Pedal distortion circuit to date – the Sunn O))) HalfLife Octave Distortion + Booster. Half the size, just as heavy.

Specifications

Dimensions

5.00 × 2.75 x 2.25 in. (127 × 70 x 57 mm) with knobs

Current Draw

15 mA

Octave Distortion

Input Impedance: 1 MΩ
Output Impedance: <1 kΩ

Booster

Input Impedance: 500 kΩ
Output Impedance: <1 kΩ

Flexi-Switch® Technology

This device features Flexi-Switch® Technology! This relay-based, true bypass switching style allows you to simultaneously use momentary and latching style switching.

• For standard latching operation: tap the footswitch once to activate the effect and then tap again to bypass.

• For momentary operation: hold the footswitch down for as long as you’d like to use the effect. Once you release the switch the effect will be bypassed.

Since the switching is relay based, it requires power to pass signal.

Power

This device takes a standard 9 volt DC power supply with a 2.1mm negative center barrel. We always recommend pedal-specific, transformer-isolated wall-wart power supplies or multiple isolated-output supplies. Pedals will make extra noise if there is ripple or unclean power. Switching-type power supplies, daisy chains and non-pedal specific power supplies do not filter dirty power as well and let through unwanted noise. DO NOT RUN AT HIGHER VOLTAGES!

Artwork by

Stephen O’Malley

Irradiated rat fossil drawing by

Savage Pencil
