DOD Morley Wah-ocTo-Fuzz Pedal

Description

Not every day do two legendary companies unite to create something truly remarkable, and that’s precisely what DOD and Morley have achieved with the Wah-ocTo-Fuzz™. By blending DOD’s classic 1986 FX35 Octoplus with Morley’s timeless wah and infusing it with the iconic Morley 70’s fuzz circuit, we have crafted a pedal that stands apart from the rest. While many have attempted to combine Wah with Fuzz, or Fuzz with Octave, this product masterfully harmonizes all three – Wah, Octave, and Fuzz – in our Wah-ocTo-Fuzz™, or simply…WTF!

Beneath its surface lurks the DOD FX35 Octoplus, a classic analog octave circuit that channels the captivating, glitchy essence of the 80’s. The Wah and Fuzz circuits draw inspiration from the timeless sounds of Morley’s 70’s era. This remarkable three-in-one pedal empowers you to explore a singular effect, or two at a time, or combine all three simultaneously. The Wah-ocTo-Fuzz™ is the ultimate tool, designed to ignite creativity in guitar, bass, and keyboard players alike.

What is old is new again! We’re embracing the vibrant energy of the 70’s and 80’s. Old school is making a triumphant return, reminding us that its essence never truly left us!

Specifications

• Dimensions: 6.84” (17.4cm) x 4.25” (10.8cm) x 1.65” (4.2cm) w/o treadle; 4.1” (10.4cm) w/ treadle (L x W x H)
• Weight: 2.26 lbs (1.02kg)
• Input: ¼” Instrument Phone Jack
• Input Impedance: >500kΩ
• Output: ¼” Instrument Phone Jack
• Output Impedance: <1kΩ
• Chassis: Cold-rolled steel
• Power Input: 2.1mm DC Barrel Jack, center (tip) negative
• Power Supply: PS0913DC Power Supply, Other well-regulated 9V center (tip) negative supply, +18 V tolerant, 9V alkaline battery
• Current Draw: 30mA typical
• Packaged Dimensions: 7.5” (8.25cm) x 4.5” (11.4cm) x 3.25” (8.25cm) (L x W x H)
• Packaged Weight: 2.7 lbs (1.22 kg)
